What is a Double Sphere Rubber Expansion Joint?
A double sphere rubber expansion joint is a flexible pipe connector made from synthetic rubber and reinforced fabric. It features two rounded arches that provide enhanced movement absorption.
It reduces stress on piping systems by absorbing axial, lateral, and angular movements while minimizing vibration and noise.
This design is widely used in HVAC systems, water pumps, compressors, and pipelines where movement and thermal expansion are concerns.
What is the Purpose of a Rubber Expansion Joint?
Rubber expansion joints serve to protect piping systems from mechanical stress due to movement, vibration, and temperature changes.
By allowing controlled flexibility, they prevent premature wear, leakage, or damage in sensitive systems.
Double sphere models offer higher compression and elongation capacity, making them ideal for dynamic environments like pump connections or building services.
What is the Purpose of an Expansion Joint?
The general purpose of any expansion joint—rubber, metal, or fabric—is to accommodate movement between system components.
In pipelines, they allow thermal expansion, contraction, and structural shifts without causing system failure.
Compared to metal joints, rubber types offer better noise insulation and flexibility, especially in systems prone to frequent vibration.
What is an Elastomeric Expansion Joint?
An elastomeric expansion joint is made from flexible rubber compounds (elastomers) reinforced with fabric or wire.
These joints are known for their excellent flexibility, corrosion resistance, and ability to absorb energy.
Double sphere types fall under this category and are especially effective in high-vibration and moderate-pressure environments such as HVAC units and industrial pumps.
What Are the Three Types of Expansion Joints?
Expansion joints generally fall into these categories:
-
Rubber Expansion Joints – flexible, vibration-absorbing, ideal for pumps and HVAC.
-
Metal Expansion Joints – handle high pressure and temperature, less flexible.
-
Fabric Expansion Joints – used in ducts for gases, low-pressure applications.
Among rubber joints, the double sphere model stands out due to its added flexibility and vibration dampening.
Why Choose a Double Sphere Design?
The double arch structure provides:
-
Greater movement absorption
-
Reduced water hammer effect
-
Longer service life due to lower stress concentration
This design is particularly useful for installations where extra movement compensation is required, such as in long piping runs or near rotating equipment.
Application Scenarios of Double Sphere Rubber Expansion Joints
Common uses include:
-
HVAC systems
-
Chilled water systems
-
Pump and compressor connections
-
Industrial water treatment plants
Their ability to handle vibration and minor misalignment makes them indispensable in dynamic pipeline environments.
Rubber Expansion Joint Installation Tips
To ensure safe and effective operation:
-
Align flanges properly before tightening
-
Avoid over-compressing during installation
-
Use control units if necessary for high-pressure systems
Refer to the rubber expansion joint installation guidelines to avoid premature wear or failure.
Related Product Keywords Integration
Our double sphere rubber expansion joints are also commonly referred to as:
-
Rubber expansion joint for pipe
-
Flexible hose packless expansion joints
-
Rubber union connector expansion joints
They are ideal for projects requiring vibration control, piping flexibility, and long service life.
Summary:
Double sphere rubber expansion joints provide superior flexibility, vibration dampening, and durability in piping systems.
